XAPG29602, Harmony XAP, Empty control station, zinc alloy, grey, 2 cut-outs, Ø22, 130 x 80 x 77 mm

MXN $1,291.00 - (IVA Incluido) + Envío

Sin existencias

This product is part of XAP range, an offer of metal control stations for XB4 and XB5 series of Ø 22mm pushbuttons. XAPG29602 is an empty enclosure with grey color (RAL7032). It has 2 cut-outs of diameter 30mm for 2 functions. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP65 / IP, making it ideal for operation in harsh environments It is compatible with Harmony 22mm range pushbuttons, switches and pilot lights It has a wide range of operating temperatures from -25°C to 70°C. Its dimensions are 130mm height, 80mm wide, 77mm deep. It is compatible with the Harmony XB4 and XB5 range of control and signaling units.

Harmony XAP, Empty control station, zinc alloy, grey, 2 cut-outs, Ø22, 130 x 80 x 77 mm

XAPG29602

Main
Range of Product	Harmony XAP
Product or Component Type	Die-cast empty control station
Device short name	XAPG
product destination	For Ø 22 mm control and signalling units
Number of cut-out	2 cut-outs
Colour of base of enclosure	Grey RAL 7032)
Colour of cover	Grey RAL 7032)
Control station type	Metal
Material	Die cast zinc
Sale per indivisible quantity	1
IP degree of protection	IP65 IEC 60529 IP657 NF C 20-010
Resistance to chemical agents	Special treatment can be obtained on request

Complementary
Number of vertical rows	1
Number of horizontal rows	2
Cut-out dimensions	Ø 30 mm
Cable entry	cable gland 1 x cable gland
Thread type	3/4 NPT
CAD overall width	3.1 in (80 mm)
CAD overall height	5.1 in (130 mm)
CAD overall depth	3.03 in (77 mm)
Net Weight	1.797 lb(US) (0.815 kg)
Compatibility code	XAPG

Environment
protective treatment	TH
Ambient Air Temperature for Storage	-40.0000000000…158.0000000000 °F (-40…70 °C)
Ambient Air Temperature for Operation	-13.0000000000…158.0000000000 °F (-25…70 °C)
Electrical shock protection class	Class I IEC 60536 Class I NF C 20-030
IK degree of protection	IK07 EN/IEC 62262

Ordering and shipping details
Category	22475-WALL STATIONS
Discount Schedule	CS2
GTIN	3389118381827
Returnability	No
Country of origin	MA

Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	5.9 in (15 cm)
Package 1 Width	11.8 in (30 cm)
Package 1 Length	15.7 in (40 cm)
Package 1 Weight	28.7 oz (815 g)

Contractual warranty
Warranty	18 months

Show More Show Less

Peso	5 kg
Dimensiones	15 × 15 × 15 cm
