STBXBE1300K bus extension kit, Modicon STB, BOS internal

MXN $5,737.00 - (IVA Incluido) + Envío

2 disponibles

This bus extension kit is part of the Modicon STB range, an offer of IP20 modular distributed I/Os on multiple networks and fieldbus. This BOS internal bus extension kit is furnished with 2-pin removable connector for power supply and FireWire for interface. It is a BOS module with rated supply voltage of 24V DC and input current of 400mA. It is an IP20 rated product. It is suitable for packaging, bottling, assembly, distribution, textile, printing and semiconductor machines. This product is certified by CE, FM Class 1 Division 2, CSA, UL. It is compatible with standard STB modules. The kit includes STBXTS1120, 2-terminal screw type connector, STBXBA2300 size 2 base, STBXTS2120, 2-terminal spring clamp connector and STBXBE1300 BOS module. Advantys distributed I/O solutions are simple, open and flexible, meeting needs in every stage of the product life cycle. For distributed connection to sensors and actuators from a PLC with prefabricated cables.

Buy it now

Categories: PLC's

Tags: PLC's

SKU: STBXBE1300K

bus extension kit, Modicon STB, BOS internal

STBXBE1300K

Main
Range of Product	Modicon STB distributed I/O solution
Product or Component Type	BOS internal bus extension kit

Complementary
Kit composition	STBXBE1300 BOS module STBXTS2120, 2-terminal spring clamp connector STBXBA2300 size 2 base STBXTS1120, 2-terminal screw type connector
mounting location	Beginning of extension segment
Product Compatibility	Standard STB modules
[Us] rated supply voltage	24 V
Supply circuit type	DC
Supply voltage limits	19.2…30 V
Input Current	400 mA
Output voltage	5.25 V +/- 0.21 % logic bus
Output voltage type	DC
Power supply output current	1.2 A
Electrical connection	2 pins for removable connector power supply Firewire interface
marking	CE
Overvoltage category	II

Environment
Electromagnetic compatibility	Immunity to electromagnetic interference IEC 61131-2
Product Certifications	FM Class 1 Division 2 UL CSA
Pollution degree	2 IEC 60664-1
Operating altitude	<= 6561.68 ft (2000 m)
IP degree of protection	IP20 conforming to IEC 61131-2 class 1
Ambient Air Temperature for Storage	-40…185 °F (-40…85 °C)
Relative humidity	95 % 140 °F (60 °C) without condensation
Vibration resistance	3 gn 58…150 Hz 35 x 7.5 mm symmetrical DIN rail 5 gn 58…150 Hz 35 x 15 mm symmetrical DIN rail +/-0.35 mm 10…58 Hz
Shock resistance	30 gn 11 ms IEC 88 reference 2-27

Ordering and shipping details
Category	US1PC3218215
Discount Schedule	PC32
GTIN	3595863949247
Returnability	Yes
Country of origin	FR

Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	0.984 in (2.500 cm)
Package 1 Width	3.150 in (8.000 cm)
Package 1 Length	5.118 in (13.000 cm)
Package 1 Weight	4.409 oz (125.000 g)
Unit Type of Package 2	S02
Number of Units in Package 2	42
Package 2 Height	5.906 in (15.000 cm)
Package 2 Width	11.811 in (30.000 cm)
Package 2 Length	15.748 in (40.000 cm)
Package 2 Weight	12.500 lb(US) (5.670 kg)
