STBPDT3100K power distribution kit, Modicon STB, standard, 24V DC

MXN $3,809.00 - (IVA Incluido) + Envío

16 disponibles

This product is part of the Modicon STB range, an offer of modular distributed I/O. This standard power distribution kit supports hot swapping illegal fallback. This product is compatible with most major fieldbus networks. It allows 30A permissible current for 2 minutes grounding terminal. The voltage detection threshold is <15V ±1 DC IN/OUT LED lit and ≥15V ±1 DC IN/OUT LED non lit. It is an IP20 rated product. Its dimensions are 18.4mm (width) x 65.1mm (depth) x 125mm (height) and weighs 0.13kg. It is suitable for packaging, bottling, assembly, distribution, textile, printing and semiconductor machines applications. This product is certified by FM Class 1 Division 2, CE, UL and CSA. This kit is suitable for use with mounting base STBXBA2200. The kit includes STBXTS2130, spring type connectors, STBPDT2100 module, STBXBA2200 base and STBXTS1130 screw type connectors. It supports STBXBA2200 mounting base. The Modicon LMC058 is the optimum solution for axis control and positioning, including automation functions. It forms a part of flexible machine control approach, a key component of MachineStruxure.

Buy it now

Categories: PLC's

Tags: PLC's

SKU: STBPDT3100K

power distribution kit, Modicon STB, standard, 24V DC

STBPDT3100K

Main
Range of Product	Modicon STB distributed I/O solution
Product or Component Type	Standard power distribution kit

Complementary
Kit composition	STBXTS2130, spring type connectors STBPDT3100 module STBXBA2200 base STBXTS1130, screw type connectors
[Us] rated supply voltage	24 V
Supply circuit type	DC
Power supply output current	10 A 113 °F (45 °C) input/output circuit) 12 A 86 °F (30 °C) input/output circuit) 6 A 158 °F (70 °C) input/output circuit) 8 A 140 °F (60 °C) input/output circuit) 0…4 A 86 °F (30 °C) input circuit) 0…8 A 86 °F (30 °C) output circuit)
Voltage range	19.2…30 V DC sensor/actuator bus
Hot swapping fallback	Hot swapping illegal
Protection type	Built-in overcurrent protection, 10 A time-lag output circuit Built-in overcurrent protection, 5 A time-lag input circuit Reverse polarity actuator bus
Permissible current	30 A for 2 minutes grounding terminal
Voltage detection threshold	< 15 V +/-1 DC IN/OUT LED lit >= 15 V +/-1 DC IN/OUT LED non lit
Product Compatibility	Mounting base STBXBA2200
marking	CE
Overvoltage category	II
Status LED	1 LED (Green) actuator bus power supply (OUT) 1 LED (Green) sensor bus power supply (IN)
Depth	2.6 in (65.1 mm)
Height	4.9 in (125 mm)
Width	0.7 in (18.4 mm)
Net Weight	0.29 lb(US) (0.13 kg)

Environment
Product Certifications	UL FM Class 1 Division 2 CSA
Pollution degree	2 IEC 60664-1
Operating altitude	<= 6561.68 ft (2000 m)
IP degree of protection	IP20 conforming to EN 61131-2 class 1
Ambient air temperature for operation	32…140 °F (0…60 °C) without) -13…158 °F (-25…70 °C) with derating factor)
Ambient Air Temperature for Storage	-40…185 °F (-40…85 °C)
Relative humidity	95 % 140 °F (60 °C) without condensation
Vibration resistance	+/-0.35 mm 10…58 Hz 3 gn 58…150 Hz 35 x 7.5 mm symmetrical DIN rail 5 gn 58…150 Hz 35 x 15 mm symmetrical DIN rail
Shock resistance	30 gn 11 ms IEC 88 reference 2-27

Ordering and shipping details
Category	US1PC3218215
Discount Schedule	PC32
GTIN	3595863949216
Returnability	Yes
Country of origin	MX

Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	1.0 in (2.5 cm)
Package 1 Width	3.3 in (8.5 cm)
Package 1 Length	5.5 in (14.0 cm)
Package 1 Weight	5.3 oz (150.0 g)
Unit Type of Package 2	S02
Number of Units in Package 2	24
Package 2 Height	5.9 in (15 cm)
Package 2 Width	11.8 in (30 cm)
Package 2 Length	15.7 in (40 cm)
Package 2 Weight	8.876 lb(US) (4.026 kg)
Unit Type of Package 3	P06
Number of Units in Package 3	384
Package 3 Height	29.5 in (75.0 cm)
Package 3 Width	23.6 in (60.0 cm)
Package 3 Length	31.5 in (80.0 cm)
Package 3 Weight	166.49 lb(US) (75.52 kg)
