BMXXSP1200 shielding connection kit, Modicon X80, for 12 slots

MXN $5,143.00 - (IVA Incluido) + Envío

193 disponibles

This cable shielding connection kit is part of the Modicon X80 modules. This kit is used to protect against electrostatic discharge when connecting the shielding on cordsets for connecting I/O modules. It is mounted under the rack holding the I/O modules. It is used for connecting analog, counter and motion control modules. It is also used to connect Magelis XBT operator interface to the processor. It comprises, 1 metal bar that takes the clamping rings and the earthing terminal and 2 support bases to be mounted on the rack.

Buy it now

Categories: PLC's

Tags: PLC's

SKU: BMXXSP1200

shielding connection kit, Modicon X80, for 12 slots

BMXXSP1200

Main
Range of Product	Modicon X80
accessory / separate part type	Shielding connection kit
Product or Component Type	Connector kit
Product Compatibility	12 slot backplane
Accessory / separate part destination	Backplane
Number of slots	12

Complementary
Kit composition	Two sub-bases A metal bar
Net Weight	0.9 lb(US) (0.4 kg)

Ordering and shipping details
Category	US1PC3418160
Discount Schedule	PC34
GTIN	3595863931747
Returnability	Yes
Country of origin	US

Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	1.8 in (4.5 cm)
Package 1 Width	3.5 in (9.0 cm)
Package 1 Length	20.5 in (52.0 cm)
Package 1 Weight	14.1 oz (400.0 g)
Unit Type of Package 2	S04
Number of Units in Package 2	20
Package 2 Height	11.8 in (30.0 cm)
Package 2 Width	15.7 in (40.0 cm)
Package 2 Length	23.6 in (60.0 cm)
Package 2 Weight	20.428 lb(US) (9.266 kg)
