BMXFCW503 cord set, Modicon M340, 40-way terminal, two end flying leads, 5m

MXN $3,135.00 - (IVA Incluido) + Envío

44 disponibles

This product is part of the Modicon X80 range, a common platform of modules for Modicon M580 and M340 Programmable Automation Controllers (PAC). This cordset is an accessory of I/O module. The length of this cable is 5m. This product is robust, high quality and based on the latest innovative technology. It is furnished with 40-way connector and two-end color-coded flying leads (conforming to DIN 47100) for electrical connection. It weighs 1.49kg. It is suitable for medium to large process applications. This cordset is compatible with Modicon M340 automation platform discrete I/O modules. Modicon X80 consists in a compatible modules common platform that reduce maintenance and training costs with same spare parts in stock, and unique training for different Programmable Automation Controllers (PAC).

Buy it now

Categories: PLC's

Tags: PLC's

SKU: BMXFCW503

cord set, Modicon M340, 40-way terminal, two end flying leads, 5m

BMXFCW503

Main
Range of Product	Modicon X80
accessory / separate part type	Preformed cordset
Accessory / separate part designation	Preformed cordset with one end with flying leads
Accessory / separate part destination	For I/O module with 40-way connectors
Number of cables	2
Electrical connection	1 connector 40 ways 2 ends with color-coded flying leads DIN 47100
Cable length	16.4 ft (5 m)

Complementary
Total number of wires	40
Wire section	0.0005 in² (0.324 mm²)
AWG Gauge	AWG 22
Relative impedance	10 MOhm <= 50 V 100 MOhm 50…250 V
Net Weight	3.28 lb(US) (1.49 kg)

Environment
Standards	CSA C22.2 No 142 EN/IEC 61131-2 UL 508

Ordering and shipping details
Category	US1PC3418160
Discount Schedule	PC34
GTIN	3595863920185
Returnability	Yes
Country of origin	US

Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	3.150 in (8.000 cm)
Package 1 Width	10.236 in (26.000 cm)
Package 1 Length	11.811 in (30.000 cm)
Package 1 Weight	3.177 lb(US) (1.441 kg)
Unit Type of Package 2	S02
Number of Units in Package 2	4
Package 2 Height	5.906 in (15.000 cm)
Package 2 Width	11.811 in (30.000 cm)
Package 2 Length	15.748 in (40.000 cm)
Package 2 Weight	13.007 lb(US) (5.900 kg)
Unit Type of Package 3	P12
Number of Units in Package 3	192
Package 3 Height	40.551 in (103.000 cm)
Package 3 Width	31.496 in (80.000 cm)
Package 3 Length	47.244 in (120.000 cm)
Package 3 Weight	657.490 lb(US) (298.232 kg)
