9001KT1A31, Push-to-test pilot light, Harmony 9001K, metal, polycarbonate, fresnel, amber, 30mm, 110-120V

MXN $4,235.00 - (IVA Incluido) + Envío

9 disponibles

This illuminated amber push-to-test pilot light provides an ergonomic and visual interface for your machines It is clearly distinguishable visually at a distance thanks to clear color It is impact resistant, dust resistant, water resistant and vibration resistant, making it ideal for operation in harsh environments It is easily installed into a standard 30mm diameter panel cut-outs and connected to control circuits High performance International standards & certifications (Marine ABS certification, IP66, Type 1, 2, 3, 3R, 4, 12 and 13)

Buy it now
SKU: 9001KT1A31

Push-to-test pilot light, Harmony 9001K, metal, polycarbonate, fresnel, amber, 30mm, 110-120V

9001KT1A31

Main
Range of Product Harmony 9001K
Product or Component Type Push-to-test pilot light
Device short name K
Complementary
Bezel material Metal
Mounting diameter 1.2 in (30 mm)
Lens type Fresnel plastic
Cap/operator or lens colour Amber
Bulb base BA 9s
Light block supply Via transformer 110 V AC 50/60 Hz
Via transformer 120 V AC 50/60 Hz
Shape of screw head Round
Light source Incandescent bulb
Operating Mode Push-to-test
Lens type Fresnel
[Us] rated supply voltage 110…120 V
Light block supply Via integral transformer
Contacts type and composition 1 C/O
Supply frequency 50…60 Hz
Lens material Polycarbonate
Size 30 mm
Environment
Product Certifications CSA LR25490 class 3211 03
CE
UL listed file E42259 CCN NKCR
NEMA degree of protection NEMA 1/2/3/3R/4/6/12/13
Ordering and shipping details
Category US10CS121426
Discount Schedule 0CS1
GTIN 785901035756
Returnability Yes
Country of origin MX
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 2.0000000000 in (5.08 cm)
Package 1 Width 2.300 in (5.842 cm)
Package 1 Length 4.50 in (11.43 cm)
Package 1 Weight 9.280 oz (263.084 g)
Contractual warranty
Warranty 18 months
Peso 0.263 kg
Dimensiones 5.8 × 11.4 × 5.1 cm
Product Datasheet
Instruction Sheet
Brochure
Technical Drawing
