9001KS11K1, 30mm Push Button, Type K, keyed selector switch, 2 position, key removal on left

MXN $3,534.00 - (IVA Incluido) + Envío

8 disponibles

30mm push button range is robust and offers long term reliability in heavy duty industrial applications and extreme environments. The 9001K operator have a metal operator base and the 9001SK operators have a plastic base. This very broad line of push button operators includes push buttons, emergency stop mushroom head push buttons, selector switches, key operated switches, and operators with potentiometers. Also includes pilot lights (LED, incandescent and neon), joystick controllers, wobble stick operators, and operators with multiple functions. These operators can be purchased as complete operators or as subassemblies that can be assembled by the user to meet specific requirements. The 9001 K metal 30mm push buttons are automatic selfgrounding operators requiring no additional wiring and are ABS Certified. Impact and corrosion resistant metal bezel and body ensures product continues to operate even after severe accidents. Contact blocks have terminal screw shipped back out to speed wiring and has a very large variety of accessories. Some operators have super bright LEDs for high visibility. These operators are IP 66, NEMA 4 rated (heavy duty, oil tight, water proof and dust tight without requiring boots). The 9001SK operators are also NEMA 4X corrosion resistant. The 9001K and 9001SK 30mm push button operators conforms to IEC, UL, CSA, EN and NOM standards. They are CE marked. 30mm Push Buttons are used in the automotive, machine tool, crane and hoist, food and beverage, industrial applications, material handling, petrochemical, wastewater treatment, metallurgy and many more industries.

Buy it now
SKU: 9001KS11K1

30mm Push Button, Type K, keyed selector switch, 2 position, key removal on left

9001KS11K1

Main
Range of Product Harmony 9001K
Product or Component Type Head for key selector switch
Device short name 9001K
Type of operator stay put
Operator profile key switch
Complementary
Bezel material Metal
Mounting diameter 1.2 in (30 mm)
Net Weight 0.456 lb(US) (0.207 kg)
Shape of signaling unit head Octagonal
Operator position information 2 positions
type of keylock E10
Key number E10
Key withdrawal position Left
Contacts type and composition Without contact block
Mechanical durability 500000 cycles
Product compatibility 9001KA1 side 1 or 2
9001KA2 side 1 or 2
device presentation Basic element
Operator profile Key switch
Type of operator Stay put
Size 30 mm
Cam profile 5
Environment
protective treatment TC
Ambient Air Temperature for Storage -40.0000000000…158.0000000000 °F (-40…70 °C)
Ambient Air Temperature for Operation -13.0000000000…158.0000000000 °F (-25…70 °C)
Overvoltage category Class II IEC 61140
IP degree of protection IP66 IEC 60529
NEMA degree of protection NEMA 1
NEMA 12
NEMA 13
NEMA 2
NEMA 3
NEMA 3R
NEMA 4
Standards IEC 60947-5-1
CSA C22.2 No 14
IEC 60947-1
UL 508
JIS C 4520
JIS C 852
IEC 60947-5-4
Product Certifications UL 508
NEMA
Vibration resistance 7 gn 2…500 Hz)IEC 60068-2-6
Shock resistance 50 gn IEC 60068-2-27
Ordering and shipping details
Category US10CS121426
Discount Schedule 0CS1
GTIN 785901913610
Returnability Yes
Country of origin FR
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 2.200 in (5.588 cm)
Package 1 Width 1.800 in (4.572 cm)
Package 1 Length 3.600 in (9.144 cm)
Package 1 Weight 8.000 oz (226.796 g)
Contractual warranty
Warranty 18 months
Peso 0.227 kg
Dimensiones 4.6 × 9.1 × 5.6 cm
Product Datasheet
Instruction Sheet
Technical Drawing
