| Male End Connector Style | No Connector,Cable,No Connector,Cable – IEC Stndrd Color Code |
|---|
| Number of poles | 4 |
|---|---|
| Degree of protection (IP), mounted | IP67 |
| Operating temperature | -20 °C |
| Second end conductors | Same as first end |
| Enclosure type rating | Screw-type: IP67, Snap-on type: IP65 |
| First end connector style | Female, straight (internal threads, except mini receptacles) |
| Cable type | Oil-resistant yellow PVC jacket, 24 AWG conductors, 300V |
| Material | Coupling nut: black Epoxy-coated Zinc, DC micro, Coupling nut: Nickel-plated Brass, pico, Molded oil-resistant PUR, DC micro, Molded oil resistant TPE, pico, Contact: Gold over Nickel-plated Brass |
| Bend radius | 10 x diam |
| Rated voltage | 75 V |
|---|---|
| Rated current In | 4 A |
| Assembly rating | 4A @ 60V AC/75V DC |
| Cable rating | UL CM AWM style 2661 VW-1 105°C @ 300V, CSA AWM A/B I/II 105°C @ 300V FT1 |
| With shield connection | False |
|---|---|
| Cable length | 2000 mm |
| Special characteristic | Standard |
| Second end termination style | No connector |
| Second end termination type | Cable – IEC standard color code |
| Length, approx | Connector: 47 mm (1.85 in) @ straight female |
| Product type feature | Standard- Epoxy coated Zinc for DC micro,AC micro, mini QD with 2-6 pin, Standard-Nickel plated Brass for pico, Standard-Aluminum with clear sealant for mini QD with 7-12 pin |
| Diameter | 3 core cable = 4.6 mm (0.18 in) 4 core cable = 4.6 mm (0.18 in) |
| Material of contact surface | Gold |
| Material housing | Plastic |
| Type of plug-in contact, inner side | Female (bus) |
| Mounting method | Freely positionable |
