| Cable Jacket | PVC Cbl, Yellow, UnShld,PVC Cable, Yellow, 22 AWG |
|---|---|
| Female End Connector Style | Female, Straight (int threads),Female, Straight (Int Threads) |
| Male End Connector Style | No Connector,Cable,No Connector,Cable – IEC Stndrd Color Code |
| Male Pin Count | 3-pin |
| Second End Conductors | Same as First End |
| Wire Size | 22 AWG |
| Number of poles | 3 |
|---|---|
| Degree of protection (IP), mounted | IP69K |
| Operating temperature | -20 °C |
| Number of pins | 3-pin |
| Second end conductors | Same as first end |
| Enclosure type rating | NEMA 6P, 1200 psi (8270 kPa) washdown, IP69K |
| First end connector style | Female, straight (internal threads, except mini receptacles) |
| Cable type | Oil-resistant PVC jacket, 18 or 22 AWG conductors, 300V |
| Material | Coupling nut: Epoxy-coated Zinc, Molded oil-resistant PUR, Contact: Gold over Nickel-plated Brass |
| Bend radius | 10 x diam |
| Rated voltage | 250 V |
|---|---|
| Rated current In | 4 A |
| Assembly rating | 4A @ 250V |
| Cable rating | UL AWM style 2661 VW-1 105°C @ 300V, CSA AWM A/B I/II 80°C @ 300V FT1, UV oil and water resistant |
| With shield connection | False |
|---|---|
| Cable length | 5000 mm |
| Second end termination style | No connector |
| Second end termination type | Cable – IEC standard color code |
| Diameter, approx | Connector: 14 mm (0.56 in) @ straight male |
| Length, approx | Connector: 50.8 mm (2.0 in) @ straight male |
| Height, approx | Connector: 31.8 mm (1.25 in) @ right angle male |
| Product type feature | Standard- Epoxy coated Zinc for DC micro,AC micro, mini QD with 2-6 pin, Standard-Nickel plated Brass for pico, Standard-Aluminum with clear sealant for mini QD with 7-12 pin |
| Diameter | 2 core cable: 5 mm (0.21 in), 3 core cable: 5 mm (0.21 in), 4 core cable: 5 mm (0.21 in), 5 core cable: 6.5 mm (0.25 in), 4 core cable (18 AWG): 6.5 mm (0.25 in) |
| Material of contact surface | Gold |
| Material housing | Plastic |
| Type of plug-in contact, inner side | Female (bus) |
| Mounting method | Freely positionable |
