| Housing Material | Standard Materials |
|---|---|
| Wire Size and Type | 16 AWG PVC |
| Type of mechanical accessory/spare part | Other |
|---|---|
| Panel mount thread size | 1/2 in 14NPT |
| Connector type | Mini |
| Number of pins | 9-pin |
| Enclosure type rating | IP67, NEMA 6P, 1200 psi (8270 kPa) washdown |
| Contact material | Gold-plated palladium/nickel |
| Assembly rating | 9-pin = 16 AWG: 600V @ 7A |
| Connector style | Straight female (internal threads) for all parts except for Mini and M23 where it represents straight female (external threads) |
| Insert material | PVC |
| Coupling nut material | Black epoxy-coated zinc |
| Conductors | 16 and 18 AWG, PVC insulation |
| Type of electrical accessory/spare part | Connecting cable |
|---|---|
| Wire size and type | 16 AWG, PVC |
| Color code | IEC or US or Auto |
| Conductor length | 1.8 m |
|---|
| Operating temperature | -20 °C |
|---|
