170ADO54050 discrete output module Modicon Momentum – 16 O solid state

MXN $21,232.00 - (IVA Incluido) + Envío

1 disponibles

This output module is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This discrete output base AC module offers 2 groups of 8 outputs, 16 discrete outputs with triac type. It offers discrete output voltage of 120V AC. There is an isolation between channels and bus at 1780V AC. It features 16 LEDs for channel status signaling. Its dimensions are 125mm (width) x 47.5mm (depth) x 141.5mm (height). It weighs 0.284kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, FM Class 1 Division 2, CSA and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems.

Buy it now

Categories: PLC's

Tags: PLC's

SKU: 170ADO54050

discrete output module Modicon Momentum – 16 O solid state

170ADO54050

Main
Range of Product	Modicon Momentum automation platform
Product or Component Type	Discrete output base AC
Group of channels	2 groups of 8 outputs
Discrete output number	16
Discrete output type	Triac
Discrete output voltage	120 V AC
Current per channel	0.5 A
Short-circuit protection	Internal fuse, 5 A slow-blow per group
protective treatment	TC

Complementary
[Ue] rated operational voltage	120 V AC
Discrete output current	4 A per group 8 A per module
Minimum output current	30 mA
Maximum leakage current	1.9 mA 120 V AC
Surge current	10 A for 2 cycles 15 A for 1 cycle 5 A for 3 cycles
Maximum voltage drop	<1.5 V 0.5 A at state 1
Output overload protection	Internal fuse
Response time	1/2 x 1/f (= 0.5 of one line cycle) from state 0 to state 1 1/2 x 1/f (= 0.5 of one line cycle) from state 1 to state 0
Isolation between channels and bus	1780 V AC for 1 minute
Power dissipation	7.5 W maximum 6 W typical
marking	CE
Local signalling	for channel status 16 LEDs
Current consumption	125 mA 120 V AC
Terminals description PLC n°1	(3)OUT_DIS#3 (4)OUT_DIS#4 (12)OUT_DIS#12 (8)OUT_DIS#8 TB (10)OUT_DIS#10 (1N)PW (1)OUT_DIS#1 (9)OUT_DIS#9 (1L+)PW (5)OUT_DIS#5 (13)OUT_DIS#13 (15)OUT_DIS#15 (2)OUT_DIS#2 (11)OUT_DIS#11 (6)OUT_DIS#6 (7)OUT_DIS#7 (14)OUT_DIS#14 (16)OUT_DIS#16
Depth	1.9 in (47.5 mm)
Height	5.6 in (141.5 mm)
Width	4.9 in (125 mm)
Net Weight	0.626 lb(US) (0.284 kg)

Environment
Product Certifications	CSA UL FM Class 1 Division 2
Resistance to electrostatic discharge	4 kV contact IEC 801-2 8 kV on air IEC 801-2
Resistance to electromagnetic fields	9.1 V/m (10 V/m) 80…1000 MHz IEC 801-3
Ambient Air Temperature for Operation	32.0000000000…140.0000000000 °F (0…60 °C)
Ambient Air Temperature for Storage	-40.0000000000…185.0000000000 °F (-40…85 °C)
Relative Humidity	95 % without condensation
Operating altitude	<= 16404.2 ft (5000 m)

Ordering and shipping details
Category	US1PC3118206
Discount Schedule	PC31
GTIN	3595861147560
Returnability	Yes
Country of origin	ID

Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	3.5 in (9 cm)
Package 1 Width	7.09 in (18 cm)
Package 1 Length	10.04 in (25.5 cm)
Package 1 Weight	17.4 oz (494 g)
Unit Type of Package 2	S03
Number of Units in Package 2	6
Package 2 Height	11.8 in (30 cm)
Package 2 Width	11.8 in (30 cm)
Package 2 Length	15.7 in (40 cm)
Package 2 Weight	6.535 lb(US) (2.964 kg)
Unit Type of Package 3	PAL
Number of Units in Package 3	48
Package 3 Height	23.6 in (60 cm)
Package 3 Width	31.5 in (80 cm)
Package 3 Length	18.9 in (48 cm)
Package 3 Weight	52.276 lb(US) (23.712 kg)
